Acute Injuries around the elbow
by Ntambue Kauta & Stephen Roche
- Understand neurovascular, soft tissue and range of motion assessment.
- Known X-Ray signs which need referral.
- Prolonged immobilisation will lead to stiffness and needs to be avoided.
The elbow is a complex hinge joint consisting of the radiocapitellar,ulnohumeral and proximal radioulnar joints. It allows flexion, extension and rotation of the forearm relative to the arm.
The following injuries will be discussed in this chapter:
- Elbow dislocation
- Distal humeral fractures
- Radial head fractures
- Olecranon fractures
The attending physician must follow the advanced trauma life support (ATLS)management protocol for all these high energy injuries, conduct a thorough neurovascular and soft tissue assessment,and document the findings.
The elbow joint is stabilised by strong static and dynamic anatomic structures(joint capsule, ligaments and muscles crossing the joint). It takes a high energy impact to dislocate the elbow joint.The most common dislocation pattern is posterolateral; the proximal radius and ulnar joint are often not disrupted as both bones move out of the joint posterolaterally.
- ATLS approach.
- Neurovascular status assessment.
- Soft tissue assessment.
- For grossly deformed joints and in situations where radiology facilities are not available, every dislocated joint should be documented, reduced and followed by radiography.
Helps to decide whether you are dealing with a simple or complex dislocation.
Simple dislocations have no associated fractures.
Complex dislocations are associated with certain fractures such as radial head, coronoid, capitellum or olecranon fracture.
The association of elbow dislocation,radial head and coronoid fractures is termed the ‘terrible triad’ due to the treatment challenges it poses to the treating surgeon.
After an initial clinical and radiographic assessment, the dislocation must be reduced.
Use the standard sedation protocol available.
For posterolateral dislocation (most common), a coupling of traction on the forearm, counter traction on the arm with downward pressure on the olecranon and gentle flexion should reduce the elbow.
Reassess and document neurovascularstatus. Obtain control radiographs.
Assess elbow stability by gentle extension of the elbow from 90° to 30° extension.
If stable throughout this arc, the joint is deemed stable. Immobilise in an arm sling for two weeks and start range of motion.
If re-dislocation occurs at 60o, reduce the elbow again, flex to 90°, pronate the forearm and test stability. If it is stable in pronation, then immobilise in pronation using commercially available braces or an above-elbow back slab.
If re-dislocation occurs between 90° and 60°, the joint is deemed unstable, reduce it again, immobilise in a back slab and refer to the orthopaedic surgeon for further assessment and surgical consideration.
- Attempt reduction as for simple dislocations.
- Immobilise in a back slab and refer to an orthopaedic surgeon.
- Neurovascular status must be carefully assessed and documented.
Distal and intra-articular humeral fractures
- Undisplaced extra-articular fractures may still be treated conservatively, provided they remain well-aligned (less than 15o of varus/valgus,anterior/posterior apex angulation).
- Displaced intra-articular fractures are best treated surgically to allow early range of motion and avoid elbow stiffness.
- The initial treatment is to immobilise the limb in an above elbow back slab.
- Undisplaced fractures should be treated conservatively for four to six weeks and followed by physiotherapy.
Radial head fractures
The management of isolated radial head fractures depends on the degree of displacement and the number of bony fragments.
Undisplaced fractures are treated in an arm sling for three weeks, and early range of motion is encouraged.
Angulated fractures by more than 30o should be reduced by the described technique and immobilised in an above- elbow back slab for three weeks.
Displaced isolated bony fragment from the radial head: a haematoma block with local anaesthetic is advised to relieve pain and examine for a mechanical block to pronation and supination.If there is no mechanical block, treat as for undisplaced fractures; if there is a mechanical block, the patient should be referred for surgery.
Displaced and non-reducible fractures should be referred for surgery.Radial head fractures associated with elbow dislocation should be managed as per the complex elbow dislocation treatment protocol.
Undisplaced olecranon fractures are treated conservatively in an above-elbow back slab for four to six weeks.
Displaced olecranon fractures debilitate the elbow extension mechanism (the triceps tendon pulls on the olecranon to extend the elbow). They warrant an open reduction and stable fixation to restore the extensor mechanism.
Other indications for surgical treatment include open fractures, trans-olecranon fracture dislocation, multiple ipsilateral or contralateral injuries.
