Chapter 7:


Student Authors: Lehlohonolo Ntlatlapo and Simeon Adesola

Specialist Advisors: Prof. Liesl Zühlke and A/Prof. John Lawrenson

Illustration showing doctor comforting a crying heart that is broken

This chapter covers the following topics:


Murmurs are distinct sounds which arise when blood flows through narrowed or leaky cardiac valves, or through anatomical defects.


Systolic murmurs are heard in systole, between S1 and S2. These are further classified by their timing into early, mid or late systolic murmurs. Murmurs that last throughout systole are known as holo- or pansystolic murmurs. Systolic murmurs can be functional (benign). These are known as innocent murmurs and are common in infancy and childhood, but disappear in adulthood. Febrile or exertional states are commonly associated with these murmurs. The volume of a systolic murmur is graded on a six-point scale.

Diastolic murmurs can be classified into early diastolic (regurgitation through the aortic or pulmonary valves) or mid-to-late diastolic (in mitral or tricuspid stenosis). Diastolic murmurs are almost always pathological but are not as commonly heard as systolic murmurs in children with congenital cardiac defects. The volume of a systolic murmur is graded on a four-point scale. All murmurs (systolic and diastolic) louder than grade 3 are pathological.

Table 7.1: Six-point (Levine) Grading Scale for Systolic Murmurs
Grade Volume Thrill?
1/6 Barely audible No
2/6 Soft No
3/6 Easily audible No
4/6 Easily audible Yes
5/6 Can be heard with the stethoscope partially off the chest Yes
6/6 Audible with stethoscope completely off the chest Yes
Table 7.2: Four-point Grading Scale for Diastolic Murmurs
Grade Volume Thrill?
1/4 Soft No
2/4 Easily audible No
3/4 Can be heard with the stethoscope partially off the chest Yes
4/4 Audible with stethoscope completely off the chest Yes

See related figure available here.

Table 7.3: Listening Areas for Common Paediatric Heart Murmurs
Area Murmur
Upper right sternal border Aortic stenosis or regurgitation
Upper left sternal border Pulmonary stenosis, pulmonary flow murmurs, right ventricular outflow tract obstructive murmurs, patent ductus arteriosus
Lower left sternal border Still’s murmur, ventricular septal defect, tricuspid valve regurgitation, hypertrophic cardiomyopathy, subaortic stenosis
Apex Mitral regurgitation

Clinical Features

The clinical presentation of a child with heart disease depends on the cause and severity of the heart lesion and/or the presence of complications. Below is a list of important clinical features:

Older children and teenagers may also present with:


The child with heart disease should have the following investigations:

Management of Valvar Disease

The severity of the patient’s symptoms and the severity of the lesion must be assessed (history, examination and investigations). In most valvar lesions, the patient’s symptoms are treated medically until they worsen or a specific echocardiographic variable (e.g. chamber size, gradient across a valve) necessitates further surgical management i.e. reaches a recognisable threshold. Thereafter, surgery to repair or replace the valve is recommended.


Acute rheumatic fever (ARF) is an autoimmune, inflammatory process that develops as a sequela to a group A 𝛽-haemolytic streptococcal infection e.g. ‘strep’ throat or scarlet fever. Rheumatic fever mainly affects children aged 5-15 years with a history of group A 𝛽-haemolytic streptococcal infection. It develops several weeks after the pharyngitis has resolved in some children and adolescents (0.3-3% of pharyngitis cases); see also image with signs and symptoms of rheumatic fever here.


Molecular mimicry is responsible for the tissue injury observed in ARF. The humeral and cellular immune responses of an individual who is genetically predisposed are both implicated in the development of the disease. In this process, the patient's immune response (both B-cell- and T-cell-mediated immunity) is unable to differentiate between the invading microorganism and some host tissues, leading to inflammation. The resultant inflammation may persist well beyond the acute infection and produce the manifestations of ARF. Cardiac involvement is the most serious complication of ARF and causes significant morbidity and mortality.

Clinical Features and Diagnosis

The revised Jones criteria are used to diagnose ARF. ARF is diagnosed if the patient has 1 required criterion and one of the following:

The required criteria are evidence of recent streptococcal infection:

Table 7.4: 2015 (Revised) Jones Criteria

Note: Subclinical carditis is valvar involvement diagnosed on echocardiography while clinical carditis is the presence of a murmur consistent with aortic or mitral regurgitation.


Relevant investigations include:


Primary Prevention

Administering a penicillin or another appropriate antibiotic for ARF in the patient with a sore throat (strep infection) decreases the risk of ARF by ~80%. One can prevent ARF with a 10-day course of oral penicillin V to treat pharyngitis. One may also give IM benzathine penicillin G or a benzathine/procaine penicillin combination. A single dose of IM is likely better to avoid non-compliance.

Should there be a penicillin allergy, one of the following antibiotics may be prescribed:

Secondary Prevention

The aim here is to prevent additional streptococcal infections as patients with a history of ARF are at a high risk of recurrence, which may cause further damage to the heart. The patient should be given a course of antibiotics (penicillin G benzathine; if penicillin-allergic, erythromycin or sulfadiazine). The duration of the antibiotic course depends on his/her clinical features:

The patient should also be given:

Patients must be closely monitored until all acute symptoms have resolved and they have returned to baseline function. ARF is a notifiable condition and all cases must be reported to the relevant local authority.



It is a cardiac manifestation of ARF (cardiac inflammation and scarring triggered by autoimmune reaction to a group A 𝛽𝛽-haemolytic streptococcal infection. In acute disease, the patient will have pancarditis [endo-, myo-, and pericarditis]). In chronic disease (2-10 years following acute rheumatic fever), the patient will have:

The mitral valve is the most commonly affected valve and the aortic valve is the second most commonly affected valve. The tricuspid valve is only affected in 10% of cases and this is often in association with mitral and aortic lesions. The pulmonary valve is rarely affected. Severe valve insufficiency in the acute state may result in heart failure and/or even death.

Clinical Features

The clinical manifestations of RHD are the same as in ARF, with/without the signs and symptoms of the associated complications.


An ECG may be done in addition to those for ARF (listed above). Sinus tachycardia often accompanies RHD, but sinus bradycardia may also occur. Other arrhythmias may develop in RHD. ECGS may also help determine which chambers are enlarged.


It may be



Congestive cardiac failure (CCF) occurs when the heart fails to meet the body’s metabolic demands at normal, physiologic venous pressure. Typically, the heart can compensate for increased demands by:

When these compensatory mechanisms fail, the signs and symptoms of CCF appear.

Systolic dysfunction is characterised by decreased ventricular contractility. It leads to an impaired ability to increase the stroke volume to meet systemic demands. Diastolic dysfunction is characterised by decreased ventricular compliance. It leads to an increase in venous pressure to maintain adequate ventricular filling.

During acute CCF, the sympathetic nervous system and renin-angiotensin aldosterone system (RAAS) maintain blood flow and blood pressure to the vital organs. Increased neurohormonal activity leads to increased myocardial contractility, selective peripheral vasoconstriction, salt and fluid retention, and, ultimately, blood pressure maintenance. As a chronic state of failure continues, these same mechanisms cause adverse effects.

In chronic heart failure, myocardial cells die from lack of nutrients, cytotoxic mechanisms (cause necrosis) or the acceleration of apoptosis. Necrosis stimulates fibroblast proliferation, which leads to the replacement of myocardial cells with collagen and scarring. The loss of myocardial cells results in cardiac dilation, an increased afterload and wall tension, and further systolic dysfunction.


The most likely causes of cardiac failure depend on the age of the child.

Foetus Neonates and Infants <2 Months Old Older Children

CHF/ hydrops can be detected with a foetal echocardiogram. At this stage, CHF may be due:

  • Underlying anaemia (reduced oxygen-carrying capacity) e.g. Rh sensitization, foetomaternal transfusion
  • Arrhythmias (usually supraventricular tachycardia)
  • Myocardial dysfunction (myocarditis, cardiomyopathy)
  • Structural heart disease (rare)
  • Respiratory illness (very common cause of heart failure)
  • Critical congenital heart disease (CHD) – can present with CCF due to structural disease; systemic and pulmonary circulation may depend on the PDA, especially in those presenting in the first few days of life
  • Primary myopathic abnormalities or inborn errors of metabolism (especially if associated with muscle weakness or lactataemia)
  • Anaemia
  • Infection
  • Left-sided obstructive disease (valvar or subvalvar aortic stenosis or coarctation)
  • Myocardial dysfunction (myocarditis, cardiomyopathy)
  • Renal failure (fluid overload and anaemia)
  • Arrhythmias (rare)
  • Hypertension (rare)
  • Illicit drug use (esp. in unexplained CHF) e.g. cocaine, other stimulants

Clinical Features

They depend on the severity of the heart failure and whether it is compensated or not. Clinical features include:

Uncompensated congestive heart failure in infants is mainly characterised by failure to thrive. This may be followed by renal and hepatic failure in severe cases. Uncompensated CCF in older children is characterised by fatigue. The child may complain of cool extremities, abdominal pain, nausea/vomiting, exercise intolerance, dizziness, or syncope.

Marked failure of one ventricle may lead to failure of the other.


One should perform:


The goals of medical therapy for CCF are to:

Thus, the following medications are given

IV hydralazine, nitroprusside and alprostadil are only used for afterload reduction in the ICU and are not easily sourced.

Other, appropriate treatment should be instituted.


The critical congenital heart diseases include:

Acyanotic Heart Diseases

Left-to-right shunting occurs because blood flows from areas of high pressure (left heart) to areas of low pressure (right heart) through a congenital structural defect in the heart.

Acyanotic heart defects include:

Atrial Septal Defect (ASD)

In this condition, blood flows from the left atrium (LA) through ASD and into the right atrium (RA) i.e. is added to normal atrial flow. On auscultation, one will hear a fixed, split second sound and grade 2/6 pulmonary ejection systolic murmur (flow murmur across the pulmonary valve). A tricuspid diastolic murmur may be heard. The child may suffer from recurrent chest infections.


One may request:


The child should undergo surgical or device closure, preferably before s/he reaches school-going age (especially if the defect is large).

Ventricular Septal Defect (VSD)

It is the most common congenital heart disease (see also related image here). Children with large defects present when they are 2-6 weeks old (slightly later but later if live at higher altitudes) as the pulmonary vascular resistance decreases from the foetal level around this time.

Clinical Features

The child will present with FTT because s/he becomes breathless during feeds as a result of the large L-to-R shunt which causes overloading and failure of the left ventricle (LV).

With an early VSD:

With a late VSD:

Although currently less common, the child with a VSD may also have a pulmonary artery band (PAB). In these patients, there is a higher RV outflow tract gradient, ejection systolic murmur and mild cyanosis.

Patent Ductus Arteriosus (PDA)

Preterm neonates often have a PDA and develop a significant L-to-R shunt in the first week of life, especially if they have been hypoxic.

Clinical Features

The infant will present with:


PDAs usually close by the time the children reach their expected term dates. However, non-steroidal anti-inflammatory drugs (NSAIDs) or paracetamol may be used to close the PDA in preterm neonates (not effective in term infants). Surgical ligation is performed if NSAIDs are not working. Ligation is required in all term infants even if they are asymptomatic because PDAs in these children do not spontaneously close (should be performed before 6-12 months). Percutaneous closure using PDA devices is the most common intervention in children beyond the neonatal period.

Atrioventricular Septal Defect (AVSD) / Endocardial Cushion Defect (ECD)

AVSDs may be complete (there is an ASD in the ostium primum and an inlet VSD with a common atrioventricular valve) or partial (there is only an ASD in the ostium primum).

It is common for a child to present with a primum ASD and a cleft in the mitral valve, which causes mitral regurgitation or allows a L-to-R shunting from the LV to the RA. The defect may be large enough to cause cardiac failure early in life. 50% of these children have Down syndrome. Thus, AVSD must be actively excluded in children with Down syndrome (must have an echo before 6 weeks of age).

Clinical Features

The child with a complete AVSD will have a pansystolic murmur at the apex (due to mitral regurgitation) and an ejection systolic murmur (due to increased pulmonary valve flow) at the left sternal border or apex. However, the absence of a murmur does not exclude a VSD.

An ECG will show left anterior hemiblock and an RSr’ pattern in V1 if there is RV hypertrophy.

Cyanotic Heart Diseases

They are the result of R-to-L shunts and may have increased or decreased pulmonary blood flow.

They may be classified as:

Tetralogy of Fallot (TOF)

It is the most common cyanotic heart disorder. In this condition, there is decreased pulmonary flow as it is characterised by:

One must always suspect TOF in any infant 6 months to 5 years old presenting with central cyanosis, RV hypertrophy, a single second heart sound and an ejection systolic murmur over the pulmonary area radiating to the left clavicle; see also diagram depicting features of Tetralogy of Fallot available here.

Pathophysiology and Clinical Features

The clinical picture depends on the degree of RV outflow obstruction. If the stenosis is severe, there will be a R-to-L shunt via the VSD. This leads to early persistent central cyanosis, clubbing, polycythaemia and acidosis (sends positive feedback to the stenosis). The lungs will be oligaemic and dark lung fields will be seen on CXR (due to the decreased pulmonary blood flow).

Clinical features include:

The child may also experience tetralogy/tet spells. During the spells, the child suddenly becomes cyanosed after crying or feeding, or when agitated due to the rapid drop in the levels of oxygen in blood.


Emergency treatment for tet spells includes

Definitive treatment of TOF is surgical repair, which is usually performed when the child weighs around 8-10 kg. It is important to note that there may be long-term issues post-repair, therefore the patient will need lifelong follow up.

Palliative procedures which may be performed include:

Transposition of the Great Arteries (TGA)

In TGA, the great arteries arise from the incorrect ventricles – the aorta from the RV and pulmonary trunk from LV. Therefore, deoxygenated, systemic venous blood travels through the RA, RV and aorta and back to the rest of the body, while oxygenated, pulmonary venous blood travels through the LA and LV and back to the pulmonary circulation. It is, therefore, a cyanotic congenital heart disease with increased pulmonary blood flow. The child has two separate parallel circuits, which is incompatible with life.

Clinical Features

The child will present with cyanosis in the 1st week of life (usually soon after birth) and is dependent on a PDA, VSD or ASD for survival. As RV outflow goes to the aorta and the LV empties into the pulmonary artery, there is severe cyanosis, CCF and LA and LV enlargement. Murmurs are not usually heard. The child develops extreme right ventricular outflow obstruction when the duct closes. Thus, mixers with unrestricted flow present when pulmonary vascular resistance drops between 4–6


All children with suspected TGA must be referred for specialist assessment and management. ECGs may point to the diagnosis but echocardiography is the main diagnostic tool (is essential). Catheterisation and CTA angiogram may be performed to assess pulmonary artery structure and size. Here is a visualisation of Transposition of Great Vessels.

The CXR will be plethoric (due to the increased pulmonary blood flow) and an egg-on-side cardiac silhouette with a narrow pedicle will be seen.


While the child is at the peripheral hospital or awaiting surgery, one should give him/her oral or (if needed) IV prostaglandin to keep the duct open. Other interventions which may need to be employed include:

Once at the referral hospital, the child will be intubated (if not already) and admitted to the PICU where she will be paralysed (or given more ketamine) and started on phenylephrine (via an arterial line). If there is no improvement, the child will have to be taken for surgery.

These children are palliated with a Rashkind atrial/balloon septostomy – allows the blood to flow from the L heart to the R heart through the septum i.e. raises peripheral SaO2 by increasing pulmonary to systemic shunting. It is then followed by an arterial switch operation.


Some of the causes of adult heart disease that start in childhood and which can be prevented include:
